In the refrigeration and air-conditioning sector, the operation and
efficiency of the equipment depend on the input values that the
instrument receives from the probe that is responsible for detecting
temperature and other physical quantities.
Temperature range: -50°C til +70°C
Dimensions: 49 x 32 x 15 mm
Dimensions: 62 x 29 x 11 mm
Cable length = 1.5 m standard (others on request)
Including 2 x LR44 Cell Batteries + on/off button on backside
Colors: White – Black - Grey
SCHLEMMER offers various materials, depending on the required temperature range, mechanical and chemical resistance.
Especially in the plastics segment, you will find a wide variety of profiles, materials and nominal sizes you can adapt individually to your own requirements.
You can even procure our Polyflex Gigant in nominal sizes of up to 95mm.
All Polyflex tubes are highly resistant to mechanical loads whilst at the same time being flexible and suitable for temperature ranges between -40°C and +260°C.
SIB - SCHLEMMER offers a huge portfolio of cable glands for industrial applications.
High quality materials and innovative technology guarantee a quality which meets the highest demands.
In the common sizes M16, M20, M25, M32, M40, M50, M63 and other sizes
Materials: metal (brass/stainless steel) and plastic (polyamide)
RoHS and REACH / SVHC compliant
Free from conflict materials
Halogen- and phosphorus-free
Fire protection class V0 according to UL 94
Protection class IP 66, IP 68 up to 10 bar and IP 69K according to DIN EN 60529
Vibration protection of the union nut
Quick mounting and optimum shield connection (EMC version)
SIB - SCHLEMMER offers a huge portfolio of cable glands for industrial applications.
High quality materials and innovative technology guarantee a quality which meets the highest demands.
In the common sizes M16, M20, M25, M32, M40, M50, M63 and other sizes
Materials: metal (brass/stainless steel) and plastic (polyamide)
RoHS and REACH / SVHC compliant
Free from conflict materials
Halogen- and phosphorus-free
Fire protection class V0 according to UL 94
Protection class IP 66, IP 68 up to 10 bar and IP 69K according to DIN EN 60529
Vibration protection of the union nut
Quick mounting and optimum shield connection (EMC version)
Renewable energy refers to all forms of energy that respect resources
from the natural world. They do not pollute and are not depleted as
they regenerate at the end of their cycle: solar, wind, geothermal,
biomass, hydro and marine energy. The monitoring of temperature and
humidity determines the potential performance of plants: in this sense,
our products play a key role in measuring these parameters.
Overheating is the number one enemy of electric motors. To ensure
their long life and proper functioning, our probes allow monitoring
directly from inside the copper windings.
Pressure sensors are widely used in Air Conditioning, Refrigeration and Heat Pump system.
YCQB is using a 5 V excitation input these sensors provide a 0.5-3.5 V or 0.5-4.5 V ratiometric signal output proportional to the pressure of the medium.
YCQC pressure sensor uses a DC 10-30V excitation input to provide a 4-20mA signal output proportional to the pressure of the medium. This device requires no end user amplification. Pressure sensors permit to control and guarantee the system working under safe and stability condition.
Sight glasses are installed after the filter drier in liquid line of refrigerating systems, in order to observe property changes of the refrigerant (liquid/vapour) and to indicate the moisture level by colours.
New models covering a wide range of refrigerants.
The filter driers of series STG are used in refrigeration system with bi-directional flow to absorb moisture and acid in the system and to filter out the impurities.
SHF series four-way reversing valves are applicable for heat pump systems such as central, unitary and room air conditioners to realize switching between cooling mode and heating mode by changing the flow path of refrigerant.
SHF series four-way reversing valves are applicable for heat pump systems such as central, unitary and room air conditioners to realize switching between cooling mode and heating mode by changing the flow path of refrigerant. SHF valves can be installed in system using flammable refrigerants HFO (categories A2 and A2L*), and Hydrocarbons HC (category A3*).
The ball valve of series SBV is applicable for commercial air conditioner, freezing or deep-freezing equipment or other refrigeration circuits in order to open and to shut off inner flow path by operating the valve stem. It can also be used as service valve for vacuum pumping and refrigerant injection etc.
RFKH series thermostatic expansion valves are used to adjust mass flow of refrigerant into the evaporator while controlling the refrigerant´s superheat at the outlet of the evaporator. They can be used for various refrigerants under all working conditions. Typical applications are refrigeration systems like freezers, ice makers, dehumidifiers as well as air conditioners and heat pumps at various evaporation temperature ranges.
RFGB series thermostatic expansion valves are used to adjust mass flow of refrigerant into the evaporator while controlling the refrigerant´s superheat at the outlet of the evaporator. They can be used for various refrigerants under all working conditions. Typical applications are refrigeration systems like commercial refrigerators and freezers, icemakers, dehumidifiers as well as air conditioners at various evaporation temperature.
RFGB 06 series has been designed and optimized for application with propane (R290)
Pressure controls can be used in refrigeration and air conditioning systems to protect the systems from extremely low suction pressure or extremely high discharge pressure. The pressure controls are also used to start or stop the refrigeration compressors and air-cooled condenser fans, to regulate other components in the systems which require pressure control function.
MDF series solenoid valves are direct operated or pilot operated solenoid valves, mainly used in refrigerant control of various devices such as refrigerating and freezing systems, air conditioners and heat pumps.
FDF2AK series solenoid valves are direct operated, normally open solenoid valves, mainly used in refrigerant control of various devices such as refrigerating and freezing systems, air conditioners and heat pumps.
FDF series solenoid valves are direct operated or pilot operated solenoid valves, mainly used in refrigerant control of various devices such as refrigerating and freezing systems, air conditioners and heat pumps.
All the Solenoid Valves listed in this datasheet can be installed in system using flammable refrigerants.
HFO (categories A2* and A2L*), and Hydrocarbons HC (category A3*).
For fluids GROUP 1 according to Directive 2014/68/EU or GROUP A3/A2L according to ANSI-ASHRAE 34-2016)
T/S series electronic expansion valves are designed for use in air conditioning and refrigeration systems or in heat pumps. The valve controls the automatic adjustment of refrigerant flow rate and makes the system work under optimized conditions for the purpose of fast cooling or heating, precise temperature control and energy saving. The valve can also be used e.g. for suction line pressure controls. These valves provide bidirectional operation to control the refrigerant flow rate in heating or cooling mode.
